EQUIPMENT FOR SALE
CABLE SPOOLING MACHINE
CLICK ON IMAGE
CLICK ON IMAGE
CLICK ON IMAGE
Model: Cable Spooling Machine
Power:
- STAFFA Radial Piston Hydraulic Motor
- Detent Hydraulic Control Valve
- Reduction Gearbox w/ Jaw Clutch
- Static Spring Held Park Brake / Pneumatic Release
- Kobelt Spinghel Pneumatic Release Disc Bracek for Holdback Tension
- 30 Gallon Air Receiver for Control Function
Drum Size / Capacity:
- Adjustable Sliding Cone for Varying Spool Width
- Flange Diameter Up to 8 Feet
- Spool Length up to 5 Feet
Line Pull:
- At 1 Foot Radius – 30,000 lbs
SMATCO 48-DAW-100
SMATCO 48 DAW
SMATCO 48 DAW
SMATCO 48 DAW
Model: SMATCO 48-DAW-100
Description: Diesel Driven, Double Drum, Waterfall Winch
Power:
- Radiator Cooled GM 4-71
- Allison TRT-2421 Transmission
Drum Size / Capacity:
- Flange Diameter – 66″ 2250FT of 2″
- Barrel Diameter – 20″ 3000FT of 1.75″
- Barrel Length – 36″ 4100FT of 1.5″
Stall Line Pull:
- 1st Layer 150,000LBS
- Mid Drum 80,000LBS
- Full Drum 54,000LBS
SMATCO 72-DAW-250
SMATCO 72 (1)
CLICK ON IMAGE
SMATCO 72 (2)
CLICK ON IMAGE
SMATCO 72 (3)
CLICK ON IMAGE
Model: 72-DAW-250
Description: Diesel Driven, Double Drum, Waterfall Winch
Power:
- GM 12V71
- Twin Disc 11500 Series
- 3 Stage Torque Converter
- SMATCO 644 Reverse Gear
Drum Size / Capacity:
- Flange Diameter – 75″ – 2300 Feet of 2.5″
- Barrel Diameter – 30 ” – 3000 Feet of 2.25″
- Barrel length – 48″ – 3600 Feet of 2″
Brake Holding: 400,000 lbs on 1st Layer
Stall Line Pull:
- 1st Layer – 350,000 lbs
- Mid Drum – 211,000 lbs
- Full Drum – 149,000 lbs
SMATCO 44-DPS-75
SMATCO 44 (1)
SMATCO 44 (2)
SMATCO 44 (3)
Model: 44-DPS-75
Description: Diesel Driven, Single Drum Winch
Power:
- GM 3-71
- Allison TRT-2421-3 Powershift Transmission
- 2 Speed FWD & Reverse
Drum Size / Capacity:
- Flange Diameter – 44” – 3300 Feet of 1”
- Barrel Diameter – 18 ” – 2600 Feet of 1-1/8″
- Barrel length – 48″ – 2100 Feet of 1-1/4″
Stall Line Pull:
- 1st Layer – 50,000 lbs
- Mid Drum – 29,000 lbs
- Full Drum – 21,000 lbs
SKAGIT RB 90
RB90-1-5
RB90-1-4
RB90-1-3
RB90-1-2
Model: RB-90
Description: Diesel Driven, Double Drum Winch
Power:
- GM 6V-71
- Twin Disc 10,000 Series Torque Converter
- Twin Disc RR 300 Reverse Gearbox
Drum Size / Capacity:
- Flange Diameter – 50” – 3750 Feet of 1-1/4”
- Barrel Diameter – 19 ” – 3160 Feet of 1-3/8″
- Barrel length – 42″ – 2600 Feet of 1-1/2″
Stall Line Pull:
- 1st Layer – 165,000 lbs
- Mid Drum – 100,000 lbs
- Full Drum – 65,000 lbs
SKAGIT RB 90
RB90-2-1
RB90-2-2
RB90-2-3
Model: RB-90
Description: Diesel Driven, Double Drum Winch
Power:
- GM 6V-71
- Twin Disc 10,000 Series Torque Converter
- Twin Disc RR 300 Reverse Gearbox
Drum Size / Capacity:
- Flange Diameter – 50” – 3750 Feet of 1-1/4”
- Barrel Diameter – 19 ” – 3160 Feet of 1-3/8″
- Barrel length – 42″ – 2600 Feet of 1-1/2″
Stall Line Pull:
- 1st Layer – 165,000 lbs
- Mid Drum – 100,000 lbs
- Full Drum – 65,000 lbs
SKAGIT BU 140
BU 140-1
BU 140-2
BU 140-3
Model: BU – 140
Description: Hydraulic Driven, Double Drum Winch
Power:
- Staffa Radial Piston Hydraulic Motor
Drum Size / Capacity:
- Flange Diameter – 47” – 2300 Feet of 1-1/8”
- Barrel Diameter – 19 ” – 1850 Feet of 1-1/4″
- Barrel length – 24″ – 1530 Feet of 1-3/8″
Stall Line Pull:
- 1st Layer – 203,000 lbs
- Mid Drum – 116,000 lbs
- Full Drum – 88,500 lbs
Clyde Frame 7 – 3 Drum Pneumatic Control
Clyde FR7-3 Drum Pneumatic -1
Clyde FR7-3 Drum Pneumatic -2
Clyde FR7-3 Drum Pneumatic -3
Clyde FR7-3 Drum Pneumatic -4
Clyde FR7-3 Drum Pneumatic -5
Model: Frame 7
Description: Diesel Driven, Triple Drum Winch
Power:
- 6-71 Detroit Diesel
- 10,000 Series Twin Disc Torque Converter
Drum Size / Capacity:
- Flange Diameter – 40” – 4520 Feet of 3/4”
- Barrel Diameter – 17.5 ” – 3310 Feet of 7/8″
- Barrel length – 30″ – 2540 Feet of 1″
Stall Line Pull:
- 1st Layer – 60,000 lbs
- Mid Drum – 45,000 lbs
- Full Drum – 30,500 lbs
Clyde Frame 7 – 3 Drum Manual Control
Clyde FR7-3 Drum-1
Clyde FR7-3 Drum-2
Model: Frame 7
Description: Triple Drum Winch
Power:
- No Power currently
Drum Size / Capacity:
- Flange Diameter – 40” – 4520 Feet of 3/4”
- Barrel Diameter – 17.5 ” – 3310 Feet of 7/8″
- Barrel length – 30″ – 2540 Feet of 1″
Stall Line Pull:
- 1st Layer – 60,000 lbs
- Mid Drum – 45,000 lbs
- Full Drum – 30,500 lbs
Clyde Frame 6 – 2 Drum Manual Control
Frame 6 – 1
Frame 6 – 2
Frame 6 – 3
Frame 6 – 4
Frame 6 – 5
Model: Frame 6
Description: Double Drum Winch
Power:
- GM 3-71
- Manual Multispeed Transmission
Drum Size / Capacity:
- Flange Diameter – 34” – 2920 Feet of 3/4”
- Barrel Diameter – 15 ” – 2150 Feet of 7/8″
- Barrel length – 27″ – 1600 Feet of 1″
Stall Line Pull:
- 1st Layer – 36,000 lbs
- Mid Drum – 23,480 lbs
- Full Drum – 18,000 lbs
MARKEY TDSD – 32
TDSD-32 (1)
TDSD-32 (2)
Markey TDSD-32 GA
Model: TDSD-32
Description: Diesel Driven, Double Drum Towing Winch Side X Side
Power:
- GM 6V-71
- Allison CRT-5633 Powershift Transmission
- 3 Speed FWD & Reverse
Drum Size / Capacity:
- Flange Diameter – 66” – 2000 Feet of 2”
- Barrel Diameter – 28″
- Barrel length – 37.5″
Stall Line Pull:
- Mid Drum – 85,000 lbs
Nautilus 35B2.5 Crane
35B2.5 (2)
35B2.5 (1)
35B2.5 (3)
35B2.5 GA (4)
Model: 35B2.5
Description: Box Boom Pedestal Mounted Hydraulic Crane
Power:
- Cummins 4BT3.9
- 100 Gallon Reservoir
- Walk Around Controls
- Continuous 360 Degree Rotation
Capacity:
- 6894 LBS @ 7 FT Radius
- 3409 LBS @ 40 FT Radius
Linkbelt Electric Capstan
Linkbelt Capstan 1
Linkbelt Capstan 2
Model: 100A
Description: 12″ Barrel Electric Vertical Capstan
Power:
- 10HP Electric Motor
- 3PH 230 / 460
Capacity:
- Starting Line Pull 12,000 lbs.
- Running Line Pull 6,000 lbs
Markey Electric Capstan
Markey Capstan 1
Markey Capstan 2
Model: Markey
Description: 19″ Barrel Electric Vertical Capstan
Power:
- 25 HP Electric Motor
Capacity:
- Line Pull 20,000 lbs.
SMATCO 812B Fairlead
SMATCO 812B Fairlead 2
SMATCO 812B Fairlead 1
Model: 812B
Description: 1-1/4″ Double Sheave Fairlead
Surplus / Like New
BRADEN AMS 20 P
Braden AMS20P-1
Braden AMS20P-2
Braden AMS20P-3
Braden AMS20P-4
Model: AMS 20 P
Description: Hydraulic Single Drum Winch
Surplus
45,000 LB Line Pull
480 ft of 3/4″ Wire Rope
